Hastelloy C22 Pipe Fittings Manufacturer and Supplier In Cape Town, South Africa

Khuliso Fittings, located in Cape Town, South Africa, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Hastelloy C22 Pipe Fittings. Renowned for their precision engineering and remarkable resistance to corrosion, Khuliso crafts pipe fittings that are built to endure even the most aggressive and corrosive environments. By employing cutting-edge manufacturing techniques and rigorous quality control measures, the company guarantees that each product adheres to the international standards demanded by various industries, including chemical processing, aerospace, petrochemical, and power generation. Khuliso Fittings’ dedication to quality, durability, and customer satisfaction has established them as a go-to supplier of nickel-based alloy piping components, both locally and around the globe.

Hastelloy C22 Stub End In South Africa, Hastelloy C22 Buttweld Elbow United kingdom, ASTM B366 Hastelloy Alloy C22 Pipe Fittings Cape Town, Hastelloy C22 Orangeucing Tee West Cape Town, Hastelloy® C22 Pipe Fittings in Gqeberha, ASME SB366 Hastelloy® Alloy C22 Pipe Cap Birmingham, Hastelloy C22 Buttweld Fittings Germiston.

Hastelloy C22 Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated

Hastelloy C22 Pipe Fittings are primarily made up of nickel, chromium, molybdenum, and iron, with some cobalt and manganese thrown in for good measure. This alloy is known for its outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking, whether in oxidizing or reducing environments. The fittings boast impressive mechanical strength, toughness, and thermal stability, even at high temperatures. Thanks to Hastelloy C22’s well-balanced chemistry, these fittings offer exceptional protection against a wide array of corrosive chemicals, including strong oxidizers and chlorides, making them perfect for challenging service conditions.

Hastelloy C22 Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
Alloy C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max

Hastelloy C22 Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %

Equivalent Grades for Hastelloy C22 Pipe Fittings

STANDARD	UNS	WERKSTOFF NR.	JIS	EN
Hastelloy C22	N06022	2.4602	NW 6022	NiCr21Mo14W

Hastelloy C22 45 deg. Elbow In South Africa, Hastelloy C22 Orangeucer United kingdom, Hastelloy C22 90 deg Elbow Cape Town, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in West Cape Town, Hastelloy C22 Pipe Bend in Gqeberha, Hastelloy® C22 Pipe Fittings Price List in Birmingham, Hastelloy C22 Pipe Elbow Suppliers Germiston, Hastelloy C22 Seamless Pipe Fittings South Africa.

Largest Hastelloy C22 Pipe Fittings Supplier in Cape Town, South Africa

Khuliso Fittings is a leading supplier of Hastelloy C22 Pipe Fittings in Cape Town, South Africa. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy C22 Pipe Fittings Dimensions

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Orangeucers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy C22 Pipe Fittings from Khuliso Fittings?

Hastelloy C22 Pipe Fittings from Khuliso Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy C22 Buttweld Cross Manufacturers South Africa, Hastelloy C22 Welded Pipe Fittings Exporter in United kingdom, Hastelloy C22 Elbow Cape Town, ASTM B366 Hastelloy C22 Tee West Cape Town, ASME SB366 Hastelloy C22 Unequal Tee Gqeberha, Hastelloy® C22 Straight Tees Birmingham, ASME / ANSI B16.9 Hastelloy C22 Short Stub End Germiston.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy C22 pipe fittings offer exceptional resistance to corrosion, particularly in oxidizing and reducing environments, making them ideal for chemical processing. They withstand high temperatures and aggressive chemicals, including chlorides, acids, and oxidizing agents, enhancing durability in extreme conditions. Their superior weldability and machinability ensure ease of fabrication. With excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, they maintain structural integrity in demanding applications. These fittings are versatile, suitable for pharmaceutical, marine, and power industries, ensuring long-term reliability, reduced maintenance, and cost-efficiency in critical environments.

Types of Hastelloy C22 Pipe Fittings

Are Custom Sizes Available for Hastelloy C22 Pipe Fittings?

Yes, custom sizes for Hastelloy C22 Pipe Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za.

Hastelloy C22 45 deg. Elbow In South Africa, Hastelloy C22 Orangeucer United kingdom, Hastelloy C22 90 deg Elbow Cape Town, ANSI B16.9 Hastelloy C22 Buttweld Pipe Fittings Suppliers in West Cape Town, Hastelloy C22 Pipe Bend in Gqeberha, Hastelloy® C22 Pipe Fittings Price List in Birmingham, Hastelloy C22 Pipe Elbow Suppliers Germiston, Hastelloy C22 Seamless Pipe Fittings South Africa.

Application Industry of Hastelloy C22 Pipe Fittings

Hastelloy C22 Pipe Fittings find their place in various applications that demand superior corrosion resistance along with mechanical strength and durability. They are commonly used in industries such as chemical processing, pollution control, aerospace, power generation, and nuclear reactors. These fittings are particularly suited for managing aggressive chemicals, acidic fluids, and high-temperature gases, ensuring secure and long-lasting connections. With their remarkable corrosion resistance and toughness, Hastelloy C22 pipe fittings are the preferred choice for critical piping systems operating in demanding environments all over the world.
