Hastelloy C276 Buttweld Fittings Manufacturer and Supplier In Cape Town, South Africa

Khuliso Fittings, located in Cape Town, South Africa, has built a solid reputation as a reliable manufacturer and supplier of top-notch Hastelloy C276 buttweld fittings. Renowned for their exceptional quality and precise manufacturing processes, Khuliso Fittings delivers products that adhere to strict international standards for both corrosion resistance and mechanical performance. Their Hastelloy C276 buttweld fittings are engineered to perform consistently in the toughest industrial settings, catering to industries like chemical processing, aerospace, power generation, and marine applications. With a strong commitment to excellence, Khuliso Fittings guarantees that each fitting provides long-lasting durability and optimal functionality in critical piping systems.

C-276 Hastelloy Welded Pipe Fittings Suppliers South Africa, C276 Hastelloy® ANSI B16.9 Short & Long Radius Elbow United kingdom, C276 Hastelloy 45°/90°/180° Butt weld Elbow Cape Town, Distributors of Hastelloy® Alloy C276 ASME SB366 Buttweld Orangeucer in West Cape Town, ASME B16.28 C-276 Hastelloy® Alloy Butt weld Orangeucing Tee Gqeberha, C276 Hastelloy Unequal Cross Exporters Birmingham, C276 Hastelloy Welded Fittings In Germiston.

Hastelloy C276 Buttweld Fittings Specification

Specifications	ASTM B366 / ASME SB366
Dimension Standard	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
ASME B16.9	standard for – Factory-Made Wrought Buttwelding Fittings
ASME B16.25	Buttwelding Ends.
ASME B16.28	standard for – Butt-Welded Short Radius Elbows & Returns Bends
MSS SP-43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Size Range	½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)
Seamless Butt Weld Fitting Size	1/2″ – 10″
Welded Butt Weld Fittings Size	1/2″ – 48″
Thickness	Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type	Seamless / Welded / Fabricated

Hastelloy C276 Buttweld Fittings Chemical Composition

Grade	Ni	C	Mo	Mn	Si	Fe	P	S	Co	Cr
Hastelloy C276	Balance	0.01 max	15 – 17	1.0 max	0.08 max	4 – 7	0.04 max	0.03 max	2.5 max	14.5 – 16.5

Hastelloy C276 Buttweld Fittings Equivalent Grade

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	OR	GOST
Hastelloy C276	N10276	2.4819	–	NiMo16Cr15W	NW 0276	ЭП760	ХН65МВУ

Hastelloy C276 buttweld fittings are primarily made of nickel, along with notable amounts of molybdenum, chromium, and iron. This distinctive alloy composition offers remarkable resistance to a variety of corrosive environments, including potent oxidizers and reducing agents. The fittings boast impressive mechanical properties, such as high tensile strength, toughness, and resistance to stress corrosion cracking and pitting. Hastelloy C276 retains its structural integrity across a wide temperature range, making these fittings perfect for highly aggressive chemical processes and high-temperature applications.

Hastelloy C276 Buttweld Elbow Dimensions Standard

NOMINAL PIPE SIZE	ALL FITTINGS	ALL FITTINGS	ELBOWS AND TEES	180 DEG RETURN BENDS	180 DEG RETURN BENDS	180 DEG RETURN BENDS	REDUCERS	CAPS
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Centre -to- End Dimension A, B, C, M	Centre-to- Centre O	Back-to- Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	0.19	…	…	…	0.19	0.38

Nickel Alloy C-276 Buttweld Fittings South Africa, Nickelvac® HC-276 Butt weld Pipe Fittings United kingdom, Hastelloy C-276 Equal Tee Wholesaler Cape Town, ASTM B366 Hastelloy C276 Pipe Elbow West Cape Town, C276 Hastelloy® Buttweld Tee Dealer In Gqeberha, Hastelloy C-276 Pipe Fittings Birmingham, Hastelloy® C276 Pipe Fittings Germiston.

Largest Hastelloy C276 Buttweld Fittings Supplier in Cape Town, South Africa

Khuliso Fittings is a leading supplier of Hastelloy C276 Buttweld Fittings in Cape Town, South Africa. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy C276 Buttweld Fittings Dimensions Standard

All Fittings				90°and 45° Ells and Tees	Orangeucers and Lap Joint Stub	Caps	180° Returns			Angularity Tol
Nominal Pipe Plane Size (NPS)	Outside⁽¹⁾ Diameter at Bevel	Inside⁽¹⁾ Diameter at End	Wall⁽²⁾ Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	±1/32	Not less than 87-1/2% of Normal Thickness	±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	10 to 12	3/32	3/16
4	±1/16	±1/16		±1/16	±1/16	±1/8	±1/4	±1/4	±1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	±1/16		±1/16	±1/16	±1/4	±1/4	±1/4	±1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	±1/8		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	±3/32		±3/32	±3/32	±1/4	±3/8	±1/4	±1/16
	-3/32

Why Choose Hastelloy C276 Buttweld Fittings from Khuliso Fittings?

Hastelloy C276 Buttweld Fittings from Khuliso Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Hastelloy Grade C-276 Butt weld Pipe Fittings Stockists In South Africa, Alloy C276 Pipe Fittings Suppliers United kingdom, UNS N10276 Nickel Alloy Butt weld Seamless Pipe Fitting Cape Town, Werkstoff No 2.4819 Hastelloy® Butt weld Eccentric Orangeucer Traders West Cape Town, Alloy C-276 MSS-SP-43 Buttweld Swage Nipple Gqeberha, C276 Nickel Alloy Concentric Orangeucer Birmingham, MSS SP-79 Hastelloy C-276 End Pipe Cap Suppliers Germiston, Hastelloy® Alloy JIS NW 0276 C276 Stub Ends Exporters South Africa, Nicrofer® 5716 Pipe Fittings Cape Town, South Africa.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy C276 Buttweld Fittings offer numerous advantages, making them ideal for challenging environments. Their superior resistance to corrosion, including pitting, stress-corrosion cracking, and oxidation, ensures long-lasting performance in aggressive chemical processes. These fittings maintain strength and integrity even in high-temperature and highly acidic or alkaline conditions. With exceptional weldability and formability, Hastelloy C276 allows for easy fabrication into various shapes. Its excellent durability and low maintenance needs make it cost-effective over time. These properties make it a preferred choice for industries like chemical processing, power generation, and marine applications.

Types of Hastelloy C276 Buttweld Fittings

Are Custom Sizes Available for Hastelloy C276 Buttweld Fittings?

Yes, custom sizes for Hastelloy C276 Buttweld Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za.

Werkstoff No 2.4819 Hastelloy® Butt weld Eccentric Orangeucer Traders South Africa, Alloy C-276 MSS-SP-43 Buttweld Swage Nipple United kingdom, C276 Nickel Alloy Concentric Orangeucer Cape Town, MSS SP-79 Hastelloy C-276 End Pipe Cap Suppliers West Cape Town, Hastelloy® Alloy JIS NW 0276 C276 Stub Ends Exporters Gqeberha, Nicrofer® 5716 Pipe Fittings Birmingham, Hastelloy C276 Buttweld Fittings Germiston.

Application Industry of Hastelloy C276 Buttweld Fittings

These Hastelloy C276 buttweld fittings are extensively utilized in industries where extreme corrosion resistance is a must. They find common use in chemical and petrochemical plants, pollution control equipment, nuclear reactors, and aerospace systems. These fittings are particularly suited for managing aggressive fluids like acids, chlorides, and oxidizers, ensuring safe and dependable operation. Their robust corrosion resistance and mechanical strength make them essential for demanding environments, helping to prolong system life and minimize maintenance costs.
