Hastelloy Pipe Fittings Manufacturer and Supplier In Cape Town, South Africa

Khuliso Fittings, located in Cape Town, South Africa, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Hastelloy Pipe Fittings. Renowned for their precision engineering and remarkable resistance to corrosion, Khuliso crafts pipe fittings that are built to endure the toughest chemical and high-temperature conditions. By employing cutting-edge manufacturing methods and rigorous quality control, the company guarantees that each product aligns with the international standards demanded by sectors like chemical processing, aerospace, petrochemical, and power generation. Khuliso Fittings’ commitment to quality, durability, and customer satisfaction has established them as a go-to supplier of nickel-based alloy piping components, both locally and around the globe.

Hastelloy Buttweld Elbow In South Africa, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Cape Town, Hastelloy Orangeucing Tee West Cape Town, Hastelloy Pipe Fittings in Gqeberha, Hastelloy Buttweld Fittings Birmingham, ASME SB366 Hastelloy® Alloy Pipe Cap Germiston, South Africa.

Hastelloy Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated.

Hastelloy Pipe Fittings are mainly made up of nickel, chromium, molybdenum, and iron, with other elements like cobalt and manganese added based on the specific grade. This distinctive alloy mix offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking in both oxidizing and reducing environments. These fittings boast impressive mechanical strength, toughness, and stability at high temperatures, ensuring they maintain their structural integrity even in harsh chemical, thermal, and mechanical conditions.

Hastelloy Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max

Hastelloy Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %

Equivalent Grades for Hastelloy Pipe Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760

Hastelloy 90 deg Elbow In South Africa, Hastelloy 45 deg. Elbow United kingdom, Hastelloy Orangeucer, ANSI B16.9 Hastelloy Buttweld Pipe Fittings Suppliers in Cape Town, Hastelloy Seamless Pipe Fittings Manufacturers West Cape Town, Hastelloy Pipe Bend in Gqeberha, Hastelloy Pipe Fittings Price List in Birmingham, Hastelloy Pipe Elbow Suppliers Germiston, Hastelloy Buttweld Cross In South Africa, Hastelloy Welded Pipe Fittings Exporter in Cape Town, South Africa.

Largest Hastelloy Pipe Fittings Supplier in Cape Town, South Africa

Khuliso Fittings is a leading supplier of Hastelloy Pipe Fittings in Cape Town, South Africa. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy Pipe Fittings Dimensions Standard

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Orangeucers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy Pipe Fittings from Khuliso Fittings?

Hastelloy Pipe Fittings from Khuliso Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

wide range of Hastelloy pipe fittings in a variety of size In U, wall thicknesses, dimensions and tolerance to meet your project’s needs—including pipe fittings in dimension as per ASME/ANSI B16.9, ASME B16.25, ASME B16.28, ASME B16.49, MSS-SP-43 Fittings / weight & thickness of Hastelloy pipe fittings.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy pipe fittings offer numerous advantages, including outstanding corrosion resistance against harsh chemicals, oxidizing agents, and reducing environments. They excel in high-temperature applications and provide exceptional durability and strength, ensuring long-lasting performance. Hastelloy resists stress corrosion cracking, pitting, and crevice corrosion, making it ideal for demanding industries like chemical processing, marine engineering, and power generation. Their superior weldability and fabrication ease enable precise custom solutions. With a proven ability to withstand extreme conditions, Hastelloy pipe fittings are a reliable choice for critical applications requiring high performance and dependability.

Types of Hastelloy Pipe Fittings

Are Custom Sizes Available for Hastelloy Pipe Fittings?

Yes, custom sizes for Hastelloy Pipe Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za.

Hastelloy Buttweld Elbow In South Africa, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Cape Town, Hastelloy Orangeucing Tee West Cape Town, Hastelloy Pipe Fittings in Gqeberha, Hastelloy Buttweld Fittings Birmingham, ASME SB366 Hastelloy® Alloy Pipe Cap Germiston, South Africa.

Application Industry of Hastelloy Pipe Fittings

Hastelloy Pipe Fittings find their place in industries that demand superior corrosion resistance along with mechanical strength and durability. You’ll commonly see them in chemical processing plants, pollution control systems, aerospace, power generation, and nuclear reactors. These fittings are perfect for managing aggressive chemicals, acidic fluids, and high-temperature gases, providing leak-proof and long-lasting connections. Their outstanding corrosion resistance and toughness make Hastelloy pipe fittings the preferred choice for critical piping systems operating in challenging environments all over the world.
