Khuliso Fittings has built a solid reputation as a leading manufacturer and supplier of Alloy Steel F9 Forged Fittings in Cape Town, South Africa. We take pride in providing top-notch components for industrial piping systems. Our F9 forged fittings are crafted with precision from high-quality alloy steel, ensuring they deliver exceptional strength, durability, and resistance to both corrosion and high temperatures. Perfectly designed for critical applications, these fittings guarantee leak-proof connections and outstanding mechanical performance under high pressure. Khuliso Fittings supplies Alloy Steel F9 Forged Fittings that cater to the power generation, petrochemical, oil and gas, and chemical industries, all while meeting international standards for reliable, long-lasting operation in tough environments.
| Specification : | ASTM A182 F9 Forged Fittings |
|---|---|
| Size | Threaded Fittings = ½” – 4” |
| Pressure Rating | Threaded Fittings = Class 2000, Class 3000, Class 6000 |
| Type Of Pipe systems | 45 Deg Elbow, Equal tee, Full Coupling, Orangeucing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple. |
| Thread Connections | ASME B16.11 (Socket Welding and Threaded) Fittings, MSS-SP-83 (Class Unions) Fittings, ASME B16.3 (Malleable Iron Fittings) Fittings, ASME B16.4 ( Gray Iron Fittings) Fittings, ASME B16.39 (Malleable Iron Unions) Fittings, ASME B16.34 (Valves — Flanged) Fittings, ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#) Fittings. |
| Standards | ASME B16.11 (American Standard), Bs3799, MSS SP 79, JIS B2302, MSS-SP-97 (Threadolet), MSS-SP-83 (Union), ASME B36.19 (Nipple) |
| Types Of Thread | NPT Fittings, BSPP Fittings, BSPT Fittings, PF Fittings, PT Fittings, MPT |
| Applications | Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection |
| Advantages Of | Simple Usage Easy installation Economic as cheaper |
Alloy Steel F9 Forged Fittings are made up of a carefully balanced mix of chromium (1.25%), molybdenum (0.5%), carbon, manganese, silicon, phosphorus, and sulfur. This specific chemical makeup gives them remarkable tensile strength, high-temperature resistance, and corrosion resistance. Typically, these fittings showcase a tensile strength ranging from 415 to 520 MPa, a yield strength of 205 to 275 MPa, and an elongation of about 20%. The combination of chromium and molybdenum boosts creep strength and mechanical stability, making F9 forged fittings perfect for high-pressure, high-temperature pipelines, steam lines, boilers, and other essential industrial systems.
| Gr | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F9 Forged Fittings | 0.15 | 0.3 – 0.6 | 0.5 – 1 | 0.03 | 0.03 | 8 – 10 | 0.9 – 1.1 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F9 Forged Fittings | 380 | 585 | 20 |
Khuliso Fittings is a leading supplier of Alloy Steel F9 Forged Fittings in Cape Town, South Africa. We offer an extensive range of Alloy Steel F9 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F9 Forged Fittings from Khuliso Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel F9 Forged Fittings offer numerous advantages, including exceptional strength, high-temperature stability, and corrosion resistance, making them ideal for demanding industrial applications. Their chromium and molybdenum content enhances their ability to withstand harsh environments, including high-pressure and high-temperature conditions. The forged construction ensures high mechanical strength and durability, providing leak-proof connections and long service life. These fittings also offer resistance to oxidation and wear, reducing maintenance costs. Alloy Steel F9 Forged Fittings are essential for industries like oil, gas, petrochemical, and power generation, ensuring reliable performance in critical systems.
Yes, custom sizes for Alloy Steel F9 Forged Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za.
| STANDARD | UNS | WERKSTOFF NR. | Trade Name |
| ASTM A182 F9 Forged Fittings | K90941 | 1.7386 | 9Cr-1Mo |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A | Center to End 45 Deg Elbow C | O.D. of Band H | Min. Wall Thick. G | Length of Thread. Minimum (1) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| Normal Pipe Size | A | B | QTY | Weight In KG |
|---|---|---|---|---|
| ¼ | 0.81 | 0.88 | 160 | 0.20 |
| ⁄ | 0.97 | 1.00 | 130 | 0.26 |
| ½ | 1.12 | 1.31 | 100 | 0.57 |
| ¾ | 1.31 | 1.5 | 75 | 0.71 |
| 1 | 1.5 | 1.81 | 40 | 1.08 |
| 1 ¼ | 1.75 | 2.19 | 25 | 1.68 |
| 1 ½ | 2.00 | 2.44 | 18 | 2.38 |
| 2 | 2.38 | 2.97 | 10 | 3.55 |
| 2 ½ | 3.00 | 3.62 | 4 | 6.22 |
| 3 | 3.38 | 4.31 | 2 | 10.36 |
| 4 | 4.19 | 5.75 | 1 | 23.91 |
Alloy Steel F9 Forged Fittings find extensive use in power plants, petrochemical facilities, oil and gas refineries, chemical processing units, and high-pressure boiler systems. They are particularly well-suited for connecting pipelines that transport steam, gases, and corrosive fluids under high pressure and elevated temperatures. These fittings ensure leak-proof connections, outstanding strength, and dependable performance, even in the most challenging industrial settings. Khuliso Fittings provides a comprehensive range of F9 forged fittings, including elbows, to meet the diverse needs of our clients.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
