Khuliso Fittings, located in Cape Town, South Africa, stands out as a top-notch manufacturer and supplier of high-quality Incoloy 825 Forged Fittings. Known for their precision engineering and commitment to international standards, Khuliso Fittings provides components that guarantee durability, reliability, and peak performance in even the toughest industrial settings. Their Incoloy 825 Forged Fittings are specifically crafted to endure corrosive environments, high temperatures, and extreme pressure, making them perfect for the chemical, petrochemical, and marine sectors. By blending cutting-edge manufacturing techniques with strict quality control, Khuliso Fittings delivers dependable solutions that boost operational efficiency and ensure long-lasting performance.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 Forged Fittings are primarily made up of nickel (38–46%), iron (28–34%), and chromium (19–23%), with added molybdenum (2.5–3.5%) and copper (1–2.5%). This alloy showcases remarkable resistance to both oxidizing and reducing agents, acids, and stress corrosion cracking caused by chlorides. On the mechanical side, it boasts a tensile strength of 80–100 ksi, a yield strength of around 40–50 ksi, and an elongation of 30–40%, which translates to excellent toughness and formability. These characteristics make Incoloy 825 Forged Fittings incredibly durable under varying temperatures and pressures, ensuring reliability in harsh industrial environments.
Khuliso Fittings is a leading supplier of Incoloy 825 Forged Fittings in Cape Town, South Africa. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Khuliso Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 825 forged fittings offer outstanding resistance to corrosion, especially in acidic and oxidizing environments, making them ideal for chemical processing and marine applications. Their high nickel content prevents stress-corrosion cracking, while molybdenum and copper enhance resistance to pitting and crevice corrosion. These fittings maintain excellent mechanical strength and stability across a broad temperature range. They are also highly durable and versatile, supporting easy fabrication and welding. Reliable and long-lasting, Incoloy 825 forged fittings are perfect for demanding industries like oil and gas, pollution control, and power generation systems.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za
Incoloy 825 Forged Fittings are extensively utilized in the chemical processing, petrochemical, and offshore industries thanks to their outstanding corrosion resistance and ability to withstand high temperatures. They excel at managing strong acids, alkalis, and saline solutions in pipelines, heat exchangers, and reactors. Moreover, these fittings find applications in marine settings, pollution control equipment, and sulfuric acid production plants, where high strength and resistance to stress corrosion are essential. Their capacity to maintain structural integrity under extreme conditions not only ensures operational safety but also helps reduce maintenance costs and prolong service life.
