Khuliso Fittings, located in Cape Town, South Africa, is a reputable manufacturer and supplier of top-notch **Titanium Grade 2 Buttweld Fittings**. Known for their precision engineering and exceptional performance, the company provides fittings that offer remarkable corrosion resistance, strength, and durability, even in the toughest conditions. Khuliso Fittings caters to a variety of industries with products crafted to meet international standards, ensuring reliable and leak-proof connections. With a strong focus on quality and innovation, Khuliso Fittings delivers Titanium Grade 2 Buttweld Fittings that shine in chemical processing, marine, and aerospace applications.
| Specifications | ASTM B363 / ASME SB363 |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size | ½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Type | Seamless, ERW, Welded, Fabricated |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS, Custom Thickness. |
| Pipe Fittings Type | Orangeucer (Concentric & Eccentric), CAP, Stubend (Long &Short), Nipple (Barrel), Bend (Long & Short), Elbow (180 Deg., 90 Deg. & 45 Deg.), Tee (Equal & Unequal) |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
Titanium Grade 2 Buttweld Fittings are primarily made of titanium, along with trace amounts of iron (≤0.3%), oxygen (≤0.25%), carbon (≤0.08%), nitrogen (≤0.03%), and hydrogen (≤0.015%). They boast excellent ductility, weldability, and corrosion resistance. With a tensile strength of about 345 MPa and a yield strength of 275 MPa, these fittings provide outstanding toughness and formability. Their low density and high fatigue resistance make them perfect for lightweight yet robust structural systems.
Khuliso Fittings is a leading supplier of Titanium Grade 2 Buttweld Fittings in Cape Town, South Africa. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 Buttweld Fittings from Khuliso Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Titanium Grade 2 Buttweld Fittings offer numerous advantages, including exceptional corrosion resistance, particularly in acidic and marine environments. Their high strength-to-weight ratio ensures durability while keeping systems lightweight. These fittings are highly resistant to oxidation, ensuring long-term performance without degradation. Additionally, Titanium Grade 2 offers excellent weldability and formability, making installation and maintenance easier. Their resistance to stress and fatigue enhances the reliability of piping systems under extreme conditions. Ideal for industries such as aerospace, chemical, and marine, Titanium Grade 2 Buttweld Fittings provide optimal performance and longevity.
| ASME B16.9 ASTM B363 Grade 2 Fittings | Factory-Made Wrought Buttwelding Fittings | Long Radius Elbows, Long Radius Orangeucing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Orangeucing Outlet Tees, Orangeucing Outlet Crosses, Lap Joint Stub Ends, Caps, Orangeucers |
| ASME B16.28 | Short Radius Elbows, Short Radius 180-deg Returns | |
| MSS SP43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Long Radius Elbows, Straight and Orangeucing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers |
| MSS SP75 | Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers |
| All Fittings | 90°and 45° Ells and Tees | Orangeucers and Lap Joint Stub | Caps | 180° Returns | Angularity Tol | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Plane Size (NPS) | Outside(1) Diameter at Bevel | Inside(1) Diameter at End | Wall(2) Thickness | Centre-to- End Dimension A,B,C,M | Overall Length L | Overall Length E | Centre-to- Centre Dimension O | Back-to- Face Dimension K | Alignment at Ends U | Nominal Pipe SIze | Off Angle Q | Off Angle P |
| 1/2 TO 2-1/2 | +1/16 | ±1/32 | Not less than 87-1/2% of Normal Thickness | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 12 to 4 | 1/32 | 1/16 |
| -1/32 | 5 to 8 | 1/16 | 1/8 | |||||||||
| 3 TO 3-1/2 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 10 to 12 | 3/32 | 3/16 | |
| 4 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 14 to 16 | 3/32 | 1/4 | |
| 5 TO 8 | +1/32 | ±1/16 | ±1/16 | ±1/16 | ±1/4 | ±1/4 | ±1/4 | ±1/32 | 18 to 24 | 1/8 | 3/8 | |
| -1/16 | ||||||||||||
| 10 TO 18 | +1/16 | ±1/8 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | All dimensions are in inches | |||
| -1/8 | ||||||||||||
| 20 TO 24 | +1/4 | ±3/32 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | ||||
| -3/32 | ||||||||||||
Yes, custom sizes for Titanium Grade 2 Buttweld Fittings are available at Khuliso Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@khulisofittings.co.za.
Titanium Grade 2 Buttweld Fittings are extensively utilized in industries where exceptional corrosion resistance and a strong strength-to-weight ratio are essential. You’ll find them in chemical processing plants, desalination systems, and power generation units. They’re also popular in marine environments, offshore platforms, and aerospace systems, thanks to their impressive performance in both oxidizing and reducing conditions. Additionally, these fittings are used in heat exchangers, condensers, and pipelines that handle chloride or acidic media. Their reliability, durability, and erosion resistance make them ideal for long-term, high-performance operations across demanding sectors.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
